Name: B1 WCDMA B3 LTE B8 GSM 2g Backpack Imsi Catcher Device For Mobile Phone
Brand: Pinnacle Technology Co., Limited
SKU: PTC-IMSI2W
Price: 22,238.00 USD
Availability: InStock

Home > products > IMSI Catcher >

B1 WCDMA B3 LTE B8 GSM 2g Backpack Imsi Catcher Device For Mobile Phone

WCDMA B3 IMSI Catcher device

Backpack IMSI Catcher device

LTE B8 backpack imsi catcher

Place of Origin:

Shenzhen China

Brand Name:

PTC

Certification:

ISO 9000

Model Number:

PTC-IMSI2W

Request A Quote

B1 WCDMA B3 LTE B8 GSM 2g Backpack Imsi Catcher Device For Mobile Phone

Product Details

Model NO.:

PTC-IMSI2W

Power Output:

Working Frequency:

B1(WCDMA)/B3(LTE)/B8(GSM 2g)(Customized)

Covering Range:

50m-200meters

N.W:

7.5kgs

Function:

Detecting IMSI And IMEI Number

Highlight:

WCDMA B3 IMSI Catcher device

Backpack IMSI Catcher device

LTE B8 backpack imsi catcher

Payment & Shipping Terms

Minimum Order Quantity

1set

Price

Packaging Details

Carton

Delivery Time

10-20days

Payment Terms

T/T, Western Union

Supply Ability

50000

B1 WCDMA B3 LTE B8 GSM 2g Backpack Imsi Catcher Device For Mobile Phone

Get Best Price

86-755-86239323

Contact Now

Product Description

This equipment can make with nine-carrier of 4G signals, it is like a portable emergency base station, support mobile, Unicom, Telecom 4G standard user information collection and positioning. The equipment looks for the target number IMSI according to the frequency point set before leaving the factory, automatically absorbs the target after successful matching, and carries out the target positioning with the individual soldier. Device parameters and positioning target information are all controlled by the mobile phone APP.

It is mainly used in indoor or small-range scene scanning and tracking of target personnel. In addition, special scenarios such as parties, large events and other places are quickly deployed.

Items	Parameters
Working Frequency Range	B1(WCDMA)/B3(LTE)/B8(GSM 2G)(Customized)
System Standard	GSM900M/DCS1800M,WCDMA,LTE
Operators	All operators
Working Mode	Active
Output Power	2W per channel for option (customized)
Coverage distance	about 50-200meters, depend on the local RF environments
Accuracy of Positioning	<1m by signal strength
Receiving Sensitivity	> -104dBm
Antenna and Connector	Built-in high gain(<=12dBi) Omni Antennas, directional antennas for option
Power Supply	DC-12V/28V(Customized)
Upgraded debugging interface	RJ45
Data Processing	Collision analysis, accompanying analysis, statistical analysis and data query
The working method of IMSI catcher	Roll Polling

* Support for TD-LTE: B38 / B41, B39, and B40

* Support for FDD-LTE: B1, B3, and B8
* Support for IMSI scraping
* Support 4G, three-netcom function
* Support the nine carriers to work simultaneously
* Built-in high-gain directional antenna
* Coverage 0.2~100m adjustable (related to macro network environment)
* The equipment adopts separate positioning of individual soldiers
* The device separates the software and the hardware
* It can be collected for the three major carriers at the same time, and each carrier has an independent switch

The backpack or Handbag types: detection range is 50-200meters

This product can be used in various occasions and can be made with portable type, fixed type, desktop type and so on for meeting with different scenarios. All the product are customized according to clients requirement.

Antennas Specification (Customized)

Antenna Working Frequency Range	700M~3800M
Polariazation	linear vertical
Gains	<=12dBi
max power range	20W seperately

Notice: This device cannot be used for any illegal crimes and terrorist activities, only USE for the "special departments and companies officially authorized by law".
