Place of Origin:
Shenzhen China
Brand Name:
PTC
Certification:
ISO 9000
Model Number:
P8
Product Technical Parameter:
| Channel | Working Frequency | Output Power(±3dBm) |
| CH1 | 20-100 MHz | 44.77dBm |
| CH2 | 100-300MHz | 44.77dBm |
| CH3 | 300-500MHz | 47dBm |
| CH4 | 800-1000MHz | 47dBm |
| CH5 | 1520- 1670 MHz | 48.75dBm |
| CH6 | 1800-2000 MHz | 48.75dBm |
| CH7 | 2000-2200 MHz | 48.75dBm |
| CH8 | 2400-2690 MHz | 48.75dBm |
| Power: AC 220V | ||
|
Power Consumption : 1000W Mainframe weight: 53.6Kg Size(L×W×H):800×500×310 mm |
||
| Humidity: 5%-95% Running Temperature: -35 to +80 ℃ | ||
Product Details:
1.System accessory table
| No | Name | Qty | Unit | Remark |
| 1 | Antenna | 8 | pcs | Omnidirectional |
| 2 | Wire controller | 1 | pcs | |
| 3 | Line controller control line | 1 | pcs | Standard |
| 4 | Spare Line controller control line |
1 |
pcs | 20M |
| 5 | Power Line | 1 | pcs | Standard |
| 6 | Hand-pull Box | 1 | pcs | System Accessary |
| Input impedence | 50Ω |
| standing wave | ≤1.8 |
| Gain | 3dBi |
| Power Capacity | 150W |
| Direction of Polarization | Vertical Polarization |
|
Cross Modulation |
<-107dBm |
|
Interface Type |
7/16 or N-K |
|
Lightning Protection |
Direct Grounding |
| Wind Protectionnn |
60(m/s) |
|
Pole Diameter |
Φ25/40(mm) |
Product Features:
l Using UHF broadband interference technology.
l High effective power (channel power) and large interference radius.
l Imported device, slow start circuit design can avoid the mechanical switch fire phenomenon, high integration, stable work.
l Perfect self-protection function. When the device is warned of overheating fault, the shielding device will automatically shut down the failed
module to avoid the damage of the shielding device.
Product Applications:
Prisons, Recording Studios, Banks, Contract Tendering Rooms, Churches, Classrooms, Testing Facilities, Security Services, Military Units, Secret Services, News Conference Rooms, Libraries, Museums, Courts, Border Patrol and Drug Enforcement, Customs, etc.
