Waterproof IP65 Outdoor DDS Prison Cell Phone Jammers Jail Blocker with Software Control
Brand Name:
PTC
Model Number:
WP800W
Place of Origin:
Shenzhen China
Certification:
ISO 9000
MOQ:
1set
Price:
Contact Us
Supply Ability:
50000
Delivery Time:
10-20days
Payment Terms:
T/T, Western Union
Standard Packaging:
Carton
Product Details
Highlight:
Waterproof IP65 prison cell phone jammers
,Outdoor DDS prison cell phone jammers
,Outdoor DDS portable cell phone blocker
Model NO.:
PTC-WP800W
Working Channel:
8CH
Output Power:
800W
Jamming Range:
10-150m
Jamming Frequencies:
Mobile Phone 2G+3G+G+5G+WIFI
Waterproof Grade:
IP65
Software Control:
Adjust Power And Monitoring Working Status
IR Remote Control:
Turn On/off Jammer
Product Description
Detailed Specifications & Features
PTC-WP800W Outdoor Waterproof Prison Jammer is a Cellular RF Wireless Signal jamming system. It designed to block all unauthorized cellular phones and communications devices in prisons and secure facilities, it is an important part of security and crime prevention. The prison Jammer can be easily installed, operating over many frequencies bands cell phones, satellite phone, Wi-Fi and many other communications devices are disabled.
Advantages and Features:
1. Each Jammer can jam up to 8 frequencies simultaneously.
2. Supports high gain directional antennas for covering long range as far as possible
3. Specially equipped with IP65 Waterproof and solid housing for all weather protection.
4. Supports Remote control for switching ON/OFF Jammer
5. Supports Remote Access Control (computer internet software control) for controlling each band power. Failure alarms and
running time.
running time.
Jammer Failure Alarms: Such as the cabinet opened maliciously, RF cables cut off deliberately, Modules failure,Temperature
problems, the failure alarms will be sent to software.
problems, the failure alarms will be sent to software.
6. UPS and battery backup in case of mains power failure for option.
7. ON/OFF each modules separately by computer software.
8. For the cellular phone jamming, only block the downlink frequencies, not disturb the uplink to keep the BTS normal running.
9. Continuous operation, even in hot climates, with no time limit.
10. Heat sink designing combing with the fans to make system in a cooling status.
11. Secure design to avoid sabotage.
12. (VSWR) circuit protection to ensure system will not burn out in case of antenna
short circuiting or disconnection.
13. Directional antennas and 360 ºC omni antennas for option.
14. 2Years Quality Warranty
| Channels No. | Frequencies | RF Output Power +/-1dBm |
| 1 | 790-894MHz | 100W |
| 2 | 925-960MHz | 100W |
| 3 | 1805-1880MHz | 100W |
| 4 | 2110-2170MHz | 100W |
| 5 | 2620-2690MHz | 100W |
| 6 | 2400-25000MHz | 100W |
| 7 | 5150-5850MHz | 40W |
| 8 | 3400-3800MHZ | 50W |
| Total Working Channels | 8 channels (the frequencies can be customized as per request) | |
| Each band power | 40-100W | |
| Total output Power | 690W | |
| Remote Control | Support Infrared remote control and software Ethernet Access control | |
| Power Adjustable | Each band power can be adjustable by software | |
| Jamming Range | 20-100meters @-85dBm | |
| Jammer Size | 700*550*300mm(LxWxD) | |
| Antenna | 1pcs High Gain Directional Antennas fully tuned 1jammer | |
| Power Supply | AC: 110-240V/DC-48V | |
| N.W | 50Kg | |
| Working temperature/ | -20℃-+50℃ | |
| Working Humidity | 5% - 95% | |
| Temperature Protection | High/Low temperature protection | |
| Jamming Frequency Range | Mobile frequencies + wifi Signals, GPS for option | |
| Jamming target | 2G/3G/4G/5G mobile phone signals+ WIFI 2.4G, WIFI 5.8G | |
Antennas Details:
The Jammer fully tuned by one piece of high gain 17dBi big directional antenna, The Jammer supports Infrared Remote Control and RS 485 Internet Software Control, to adjust individual band power output, so you can adjust each band output power by internet directly to control the Jammer in all your country to prevent disturb others.
