Black Handheld Drone Detector Anti Quadcopter UAV Detection Systems Custom
custom Handheld Drone Detector
,Quadcopter Handheld Drone Detector
,Quadcopter uav detection systems
PTC-2HUAV is a portable and versatile tool that can be used for a variety of applications. Whether you're looking to monitor airspace for security purposes, or simply want to keep an eye on the drones flying in your area, this device is an essential tool for any drone enthusiast or security professional.
2HUAV Drone Detectors is designed to provide accurate and reliable drone detection, making it an essential tool for anyone looking to keep their airspace secure. Whether you're looking to protect a critical infrastructure facility, or simply want to keep your private property safe, this device is an essential tool for any security professional
This Remote Controlled Flying Object Finder, also known as the Drone Sensing System or Unmanned Aerial Craft Identifier, is a reliable and effective solution for detecting and identifying drones in a range of up to 2000 meters.
Technical Parameters:
- Omni-directional Detection Mode
| # | Item | Technical Parameters |
| 1 | Operating mode | Passive detection |
| 2 | Drone models supported | DJI series drones,FPVs, Xiaomi, Yuneec, Hubsan, Hubson, Powervision, Tello drones etc. |
| 3 | Working frequency | 900MHz, 2.4GHz, 5.1GHz, 5.8GHz |
| 4 | Detection range | 0-800 meters (urban environment, tested with DJI AIR2 as the target) |
| 5 | Azimuth | 0°~360°(omnidirectional antenna) |
| 6 | Recognition time | ≤2s |
| 7 | False alarm rate | ≤once/day(In an anechoic chamber environment) |
| 8 | Swarm detection | ≥10 concurrent drones |
- Direction Finding Mode
| 1 | Operating mode | Directional passive detection |
| 2 | Action object | Some drones such as DJI (Phantom series and Yu series), Daotong and Hubson |
| 3 | Working frequency | 2.4GHz and 5.8GHz |
| 4 | Detection distance | 100-2000 meters (urban environment, tested with DJI AIR2 as the target) |
| 5 | Probe azimuth | ≤±17.5°(Target 1km away with frequency locked) |
4.2 Mechanical parameters
| 1 | size | L*W*H:250mm*180mm*55mm(the host) |
| 2 | weight | ≤2kgs(Antenna included) |
| 3 | Battery life | ≥3hours |
| 4 | Charging time | ≤3 hours (using the original charger) |
| 5 | Charging interface | Type-C |
4.3 Electrical characteristics
3 Electrical characteristics
| 1 | power consumption | ≤6W |
4.4 Environmental adaptability
| 1 | Operating temperature | -20℃~55℃ |
| 2 | degree of protection | IP54 |
4.5 Battery parameters
| 1 | Nominal capacity | 5Ah |
| 2 | Nominal voltage | 16.8V |
| 3 | Battery type | lithium battery |
