Place of Origin:
Shenzhen China
Brand Name:
PTC
Certification:
ISO 9000
Model Number:
ALP10
| NO. | Item | Description | Min Typical Max | Unit |
| 1 | Frequency Band | Ku-band | 10.95 11.7 11.7 12.2 12.2 12.75 10.95 12.75 |
GHz |
| 2 | Gain | Selectable | 40 60 | dB |
| 3 | Gain Flatness | Full Band | +/-1 | dB |
| 4 | VSWR | Input Output |
1.25:1 1.5:1 |
|
| 5 | Noise temperature | 23°C | 75 90 100 | °K |
| 6 | 1dB Compression Point Power | ≥+10 | dBm | |
| 7 | 3rd Order IMD | Dual-tone-12dBm | ≤-51 | dBc |
| 8 | Gain Stability | 24 Hours | +/-0.5 | dB |
| 9 | Connector | Input Output |
Waveguide N or SMA |
|
| 10 | Input Overload | Overload 1min | 0 | dBm |
| 11 | Working Voltage | DC | +12 +15 | V |
| 12 | Working Temperature | -40~+70 | °C |
Features:
1. Wide Frequency band;
2. Low Output noise;
3. Low power consumption, high linearity;
4. Hybrid micro-assembly process, small size, high stability;
5. Wide operating temperature range;
6. Custom made available
Applications:
