Name: Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof
Brand: Pinnacle Technology Co., Limited
SKU: UAV-WP200W
Price: 22,238.00 USD
Availability: InStock

Home > products > Anti Drone Jammer >

Aluminium UAS FPV Counter Drone Jammer Signal Jamming 200W IP65 Waterproof

FPV Counter Drone Jammer

IP65 Waterproof Counter Drone Jammer

IP65 Waterproof drone signal jammer

Place of Origin:

Shenzhen China

Brand Name:

PTC

Certification:

ISO 9000

Model Number:

UAV-WP200W

Request A Quote

Product Details

Model NO.:

PTC-UAV-WP200W

Output Power:

200W

Working Frequency:

1.5g+2.4G+5.8g+900MHz+1.2g+433MHz

Jamming Distance:

100-1000meters

Waterproof:

IP65

Application:

Government+Oilfield+Airport Security

Highlight:

FPV Counter Drone Jammer

IP65 Waterproof Counter Drone Jammer

IP65 Waterproof drone signal jammer

Payment & Shipping Terms

Minimum Order Quantity

1set

Price

Packaging Details

Carton

Delivery Time

10-20days

Payment Terms

T/T, Western Union

Supply Ability

50000

Manpack Anti Drone FPV 400Mhz/900Mhz/1.2G/1.4G/1.5G/2.4G/5.2G/5.8G Drone Jammer UAV Scrambler

Get Best Price

Suitcase Portable 1.5g 2.4G 5.8g Anti Drone Jammer with Internal Antennas

Get Best Price

6-Antennas Waterproof Outdoor Fixed Anti-Drone Signal Jammer with Tripod Standing

Get Best Price

Outdoor Waterproof Anti-Drone FPV Jammer with Internal Antennas up to 7km Range

Get Best Price

86-755-86239323

Contact Now

Product Description

This high power Waterproof ANTI-DRONE JAMMER is elaborately designed as a domestic and international drone-controlling device by adopting advanced technologies both at home and abroad. It is an environment-friendly jammer. And designed to disturb low-altitude flying drone's remote control signals without influence on surrounding signals such as those for mobile communication, communication base station, car remote control and so on. The jammer is configured with 7 output channels (VHF/UHF/remote control /Wifi2.4G/5.8G/GPS positioning) to intercept drone's remote control signal, disturbing range can be up to 1km for option.

Basic Specifications
Working Frequencies: 7 Frequencies
Total Output Power: 210W
Jam Range: 100-1000meters
Power Supply: AC 220V
Product Size: 700*550*300mm(LxWxD)
Product Weight: appr.30kg

Channel #	Working Frequency (±10MHZ)		Channel Power(±3dBm)
CH1	300-450MHz		30W
CH2	450-600 MHz		30W
CH3	600-800 MHz		30W
CH4	800-1000 MHz		30W
CH5	1000-1200MHz		30W
CH6	2400-2500MHz		30W
CH7	5725-5850MHz		30W
Total Working Channels		7 channels
Total Working Output		210W
Shielding distance		100meters-1km
Jamming Objects		UAV image transmission, flight control link, navigation signal
Power Supply		AC: 110-240V
Antenna		High gain Directional antenna
Power consumption		600W
Waterproof Level		IP65
Weight		40Kg
Size(Length × width × height)		700550300mm(LxWxD) no included antennas
Humidity		5%-95%
Operation temperature		-20 to +50℃

Features and Advantages

Ultrahigh frequency board-band jamming technology
Wide coverage of 7 Frequencies with high effective power.
Waterproof designed
Long jamming Range up to 1km.
High Power and Friendly use
Support high gain Omni Antennas and Directional Panel Antennas
Effective segmentation to block each drone controlled signals.
Imported chips, slow start circuit design can avoid the sparking phenomenon caused by mechanical switch, high integration and stable operation. standing wave and other fault alarms, the drone signal jammer will automatically cut off the failed module to avoid damage to the drone shield.

How to Use:

Put the Drone jammer on the higher places and switch on then jammer works, it will cut off the signal between the controller and the drones. The drone will not be able to receive any control signals or transmit any camera signals back to the controller and drop down. The drone will be officially MIA (missing in action).

Applications:

Any sensitive locations where the drones/UAVs are not allowed to use, like Government, Oilfield, Homeland Security, Large Gathering Place, Counter-terrorism, Ar-my Security, Airport Security, Petrochemical Industry, Sports Venues, VIP Convoy Protection, Schools and Universities

etc.
