Product Description

Smart Prison Jammer System with Central Management Software Control

PTC Professional Prison Jammer designed for correctional facilities. Block 2G, 3G, 4G, 5G, and WiFi signals with wide coverage and stable operation. Unlike traditional signal jammers that block all communications, our Prison Jammer provides intelligent control with Black & White List management, ensuring both security and operational efficiency.

Why Choose Our Prison Jammer

Designed Specifically for Correctional Facilities

Our Prison Signal Jammer System is developed for prisons and detention centers where secure communication control is essential. The jammer prevents inmates from using:

Illegal mobile phones
Wireless routers
Bluetooth devices
Data connections

This ensures a secure and controlled communication environment.

Technical Parameters

Specification of PTC-AIWP400W

Channels No.	Frequencies	RF Output Power +/-1dBm
1	790-894MHz	50W
2	925-960MHz	50W
3	1805-1880MHz	50W
4	2110-2170MHz	50W
5	2620-2690MHz	50W
6	2400-2500MHz	50W
7	5150-5850MHz	50W
8	3300-3800MHz	50W

System Specifications

Total Working Channels: 8 channels (20-6000MHz frequencies for option)
Each band power: 50W
Total output Power: 400W
Integrated Function: Blacklist & Whitelist Control for option
Remote Control: Support Infrared remote control and software Ethernet Access control
Power Adjustable: Each band power can be adjustable by software
Jamming Range: 50-300 meters @-85dBm
Antennas: 1pc High Gain Directional Antennas fully tuned per jammer
Jammer dimension: 700*550*300mm (LxWxD)
Jamming technology: SDR Solutions
Power Supply: AC: 110-240V/DC-48V
Waterproof grade: IP65
N.W: 50Kg
Working temperature: -20ºC to +50ºC
Working Humidity: 5% - 95%
Temperature Protection: Over High/Low temperature protection
More protection: VSWR over protection, lightning protection
Jamming Frequency Range: Mobile frequencies + wifi Signals, GPS for option
Jamming target: 2G/3G/4G/5G mobile phone signals + WIFI 2.4G, WIFI 5.8G

Access Control Features

White List Function

Allow Authorized Devices

The White List allows selected devices to operate normally inside the jammer coverage area.

Authorized devices may include:

Staff mobile phones
Emergency communication devices
Security radios
Official communication terminals

Benefits:

Staff can communicate normally
Emergency calls remain available
No interference with official operations
Improved facility efficiency

Black List Function

Block Unauthorized Devices

The Black List automatically blocks unauthorized mobile devices.

Blocked devices include:

Illegal inmate mobile phones
Smuggled smartphones
Wireless hotspots
Unauthorized terminals

Blocking Methods

IMEI based blocking
IMSI based blocking
Device ID recognition

System Design Features

Modular Design

Each frequency module works independently.

Advantages:

Easy maintenance
Flexible configuration
Upgradeable system

24/7 Continuous Operation

Industrial-grade design ensures long-term operation.

Features include:

Smart cooling system
Overheat protection
Stable power supply
Heavy-duty housing

Suitable for permanent installation.

System Capability

Block illegal phones while allowing authorized devices. Custom solution available.
